MV-CH050-60UM

Key Feature Adopts brand new structure design and supports installation from four sides. Supports Sequencer, Super Palette and Super Bayer to provide high-quality images. Supports auto or manual adjustment of gain, exposure time, white balance, LUT, Gamma correction, etc. Supports hard trigger, software trigger, free run, etc. Supports customized ROI, horizontal and vertical reverse image output. Compatible with USB3 Vision Protocol, GenlCam Standard, and the third-party software based on the pr

상세 스펙

시리즈	CH AreaScan
제조사	Hikvision
센서	Stacked BSI
센서 크기	8.4 x 7.1 mm
픽셀 크기	3.45 µm
해상도	2448 × 2048
속도	79 fps
셔터	Global
컬러/모노	Mono
인터페이스	USB3.0
마운트	C
제품 크기	29 × 29 × 30 (1.1" × 1.1" × 1.2")
무게	Approx. 80 g (0.2 lb.)
전원	9 VDC to 24 VDC, supports USB 3.0 power supply
소비전력	1.9
